Field Description Description
360°MINI Leica prism constant:
30.0 mm
Foil
Leica prism constant:
34.4 mm
Custom The user can dene their own prism.
Constants can be entered in mm in Leica
Const:.
Leica constant = Absolute constant +
34.4 mm
Meas.
Mode:
Standard For distance measurements with prisms.
Quick Quick measuring mode with prisms, with
higher measuring speed but lower accuracy.
Track For continuous distance measurements with
prisms.
Average Repeats three measurements in standard
measuring mode. The average distance and
the standard deviation for the averaged dis-
tance are calculated.
Repeat Repetitive measurements with standard
accuracy.
Leica Const: Editable eld This eld displays the Leica constant for the
selected Prism Type:.
Where Prism Type: is Custom this eld
becomes editable to set a user dened con-
stant.
Input can only be made in mm.
Limit value: -999.9 mm to +999.9 mm.
Laser: OFF Visible laser beam is deactivated.
ON Visible laser beam for visualising the target
point is activated.
This screen enables the entry of atmospheric parameters. Distance measure-
ment is inuenced directly by the atmospheric conditions of the air in which
the measurements are taken. In order to take these inuences into consid-
eration distance measurements are corrected using atmospheric correction
parameters.
The refraction correction is taken into account in the calculation of the height
differences and the horizontal distance. Refer to 13.6 Scale Correction for the
application of the values entered in this screen.
☞
When PPM0 is selected, the Leica standard atmosphere of 1013mbar
and 12°C is applied.
EDM Setting - Atmos
