13.3 Distance Measurement without Reectors
(Non-Prism mode)
Kodak Gray Card [m]* [ft]*
White side
90% reective
500 1640
Grey side
18% reective
200 820
* The distance range can vary depending on the conditions and can
be above or below the specied value. The specied range value is
referring to non-extreme conditions, visibility about 20 km, moder-
ate sunlight, slight heat shimmer.
ISO17123-4 Measure time, typical [s]
Standard measuring 3 mm + 2 ppm 1.1 in Quick mode
1.4 in Standard mode
>200m 5 mm + 3 ppm -
Beam interruptions, severe heat shimmer and moving objects within the beam
path can result in deviations of the specied accuracy and measurement time.
Distance [m] Laser dot size, approximately [mm]
at 50 12 × 24
Type Description
Principle Phase measurement
Type Coaxial, visible red laser
Carrier wave 685 nm
Measuring system Phase surveying about 75 MHz (74.926925 MHz)
13.4 General Technical Data of the Product
Type Value
All-around rotation
Magnication 28 x
Objective diameter 44 mm
Focusing range 1.50 m/4.92 ft to innity
Field of view 1°30’/1.66 gon
Field width at 100 m 2.8 m
Compensator range: ±8'
Type Value
Longitudinal level sensitivity 2’/2 mm
Range
Accuracy
Laser dot size
Characteristics
Telescope
Compensation
Level
