Leica TS01 - Projections

P1 Start point
P2 Target point
P3 Target point
a Reference height
d1 Height difference between start point and the reference height
d2 Height difference between P2 and the reference height
d3 Height difference between P3 and the reference height
1. Align to the target point.
2. Select Reine Measurement from the Reference Line menu.
3. A measurement is taken.
4. The corrdinates and the offset values are displayed.
Key Description
Meas To execute a distance measurement and store the displayed
values.
Store To save the displayed values without executing a distance
measurment.
To display the next elds.
Description of elds
Field Description
T-Offset: Calculated distance perpendicular from the reference line.
L-Offset: Calculated distance longitudinal to the reference line.
H-Offset: Calculated height difference relative to the dened reference
height.
7.9.5 Projections
Projects a point perpendicular onto a reference line. The initial coordinates
of the point can be either measured, manually entered, or selected from the
memory.
Displayed are:
•
Coordinates of the projected point on the reference line
•
Offsets between the initial point and the calculated point on the refer-
ence line
Access
Reine Measurement
Description
Apps 65
