Leica TS01 - Page 5

6.4 Selecting the Orientation 46
6.4.1 Overview 46
6.4.2 Orientation with Angle 47
6.4.3 Orientation with Coordinates 47
6.5 Setting the Job 48
7 Apps 49
7.1 Common Fields 49
7.2 Survey 49
7.3 Set Out 49
7.4 Target Offset 51
7.4.1 Overview 51
7.4.2 Distance Offset 52
7.4.3 Angle Offset 53
7.4.4 Double Distance Offset 54
7.4.5 Cylindrical Offset 55
7.5 Missing Line Measurement 56
7.6 Remote Elevation 58
7.7 Area 58
7.8 Resection 59
7.9 Reference Line 61
7.9.1 Overview 61
7.9.2 Dening the Reference Line 61
7.9.3 Stakeout 63
7.9.4 Measuring to a Reference Line 64
7.9.5 Projections 65
7.10 Road 67
7.10.1 Overview 67
7.10.2 Basic Terms 68
7.10.3 Creating a New Alignment 70
7.10.4 Stake 73
7.10.5 Data Transfer 75
8 Coding 78
9 Data Management 79
9.1 Overview 79
9.2 Memory Information 79
9.3 Deleting the Memory 80
9.4 Working with a USB Memory Stick 80
10 Data Transfer 82
10.1 Exporting Data 82
10.2 Importing Data 83
11 Tools 84
11.1 Check & Adjust 84
11.1.1 Overview 84
11.1.2 Preparation 84
11.1.3 Adjusting Line-of-Sight and Vertical Index Error 85
11.1.4 Adjusting the Compensator 87
11.1.5 Adjusting the Level of the Instrument and Tribrach 88
11.1.6 Inspecting the Laser Plummet of the Instrument 88
11.1.7 Servicing the Tripod 89
11.2 System Information 90
11.3 Loading Firmware or License 90
12 Care and Transport 92
12.1 Transport 92
Table of Contents 5
