WARNING SYMBOLS
LELY WELGER y RPC 445 Tornado 17
2.2.4 Hydraulic connections
Meaning
Hydraulic brake Return flow:
Pick-up
HYDROFLEX
cutting device
Pressure:
Pick-up
HYDROFLEX
cutting device
Return flow:
Bale wrapper
Tailgate
Net knife
Pressure:
Bale wrapper
Tailgate
Net knife
Load sensing
Connection sizes
– Size 3 Size 3 Size 5 Size 3 Size 3
Oil flow direction
෣ ෥ ෣ ෥ ෣ ෥
Decal
0384.31.00.00
0388.18.00.00 0388.18.00.00 0389.80.00.00 0388.26.00.00 0384.32.00.00
