SAFETY
LELY WELGER y RPC 445 Tornado 25
3.8 Emergency stop
Attention, danger of injury!
In the tractor cabin and on the left and right of the machine
frame an emergency stop palm button is installed. In case of
emergency: Immediately stop (shut down) the machine by
pressing an emergency stop palm button.
The three EMERGENCY STOP palm buttons switch off the
control electronics of the baler and of the wrapper. All
hydraulic (oil-operated) movements are stopped. But: All
units driven by the power take-off shaft are continue to run
(e.g. net tying system, rollers, draw-in screws, pick-up tines)!
(Figure 6) Emergency stop palm button [1]
in the tractor cabin
(Figure 7) Emergency stop palm button [1]
on the control box (left machine side).
(Figure 8) Emergency stop palm button [2]
on the machine frame (right machine side).
Emergency stop palm buttons
Figure 6
Figure 7 Figure 8
