Configuration
36 Power Analyzer NORMA 4000, NORMA 5000
EO1111G REV G
Note
The integration function is enabled (ON) in the factory configuration
1:W3 .
Menu Integration Setup, second field column State is highlighted
Press Enter, select AUTO and confirm with Enter.
Clear values at start is now enabled. If you want to change it,
select MAN and confirm with Enter
Save the settings with SAVE in the desired configuration.
Note
In the factory configuration 1:W3 the function clear manual (MAN)
is preselected.
You can select different start conditions:
Column Settings description
Trig remote
time
key
Start via Interface command
Start on date and time
Start when key pressed (Key F1)
at -Date- Start time(only active at Trig time)
after -
No function
Menu Integration Setup, first field column Trig is highlighted
Press Enter, select start condition and confirm with Enter.
Start condition is now set. If you have selected a time to start
(time) enter the time in the column at. Proceed as described
below:
Menu Integration Setup, first field column at is highlighted
Press Enter, select year, month, day, hour minute and seconds
with the cursors and confirm with Enter.
Start time is now set.
Save the settings with SAVE in the desired configuration.
Note
Date and time for start is taken from the clock in the unit. Please
control date and time of the unit before you start the integration
calculation (7.5“Adjust date and time” page 29).
You can select different stop conditions:
Column Settings Description
Trig remote
time
key
ti-int
Stop via Interface command
Stop at date and time
Stop when key pressed (Key F2)
Stop after time window
at -Date-
Stop on date and time (only
active at Trig time)
after -time-
Integrations time window in sec.
((only active at Trig ti-int)
Configure start
Configure stop
