LEM NORMA 5000 - Current Channel Diagram

Technical Data
Power Analyzer NORMA 4000, NORMA 5000 77
EO1111G REV G
0,03 A
0,3 A
0,03 V 0,1 V
10 A
1 A
0,1 A
0,3 V 1 V 3 V 10 V
3 A
1 W ... int. Shunt 1
0,1 W ... int. Shunt 2
0,01 W ... int. Shunt 3

offon



Filter Triggerlevel Slope
Settings
CLK
CLK
Analog-Digital
Converter
Galvanic
separation
Data I
CLK
Settings I
CLK
Sample/HoldAnti-Aliasing
Ranges I
Hi
Lo
Ext.
Shunt
100
Hz
1
kHz
10
kHz
off
Filter
Current channels
