CAUTION:
The power-control button on the device and the power switch on the power supply do not turn off the
electrical current supplied to the device. The device also might have more than one power cord. To
remove all electrical current from the device, ensure that all power cords are disconnected from the
power source.
Attention:
• Read “Installation guidelines” on page 57 to ensure that you work safely.
• Power off the server and disconnect all power cords for this task.
• Prevent exposure to static electricity, which might lead to system halt and loss of data, by keeping static-
sensitive components in their static-protective packages until installation, and handling these devices with
an electrostatic-discharge wrist strap or other grounding system.
• If the server is in a rack, remove it from the rack.
• If foot stands are installed on the server, rotate them inwards and lay the server on its side for easier
operation.
Watch the procedure. A video of the installation and removal process is available:
• YouTube:
https://youtube.com/playlist?list=PLYV5R7hVcs-DoEcxrm2zKNpaKOdZ3f8Qc
• Youku: https://list.youku.com/albumlist/show/id_59636516
Procedure
Step 1. Make preparations for this task.
a. Remove the server cover. See “Remove the server cover” on page 188.
b. Remove all the flash power modules. See “Remove a flash power module” on page 98.
c. Remove the air baffle. See “Remove the air baffle” on page 72.
d. Remove all the full-length GPU adapters. See “Remove a full-length GPU adapter” on page
113.
e. Remove all the fans. See “Remove a hot-swap fan” on page 93.
f. Remove the fan cage. See “Remove the fan cage assembly” on page 95.
g. Remove all installed simple-swap drives and drive bay fillers (if any) from the drive bays. See
“Remove a simple-swap drive” on page 80.
Step 2. Disconnect all cables connected to the system board.
Step 3. Remove the backplate.
