Electrical installation − EMS version
Control terminals
Interfaces RS485 PLC
7

134
EDS84DPS424 EN 5.0
7.6.5 Interfaces RS485 PLC
These connections are available with device versions:
ƒ E84DDxxxxxxxCxBxxx
ƒ E84DExxxxxxxCxBxxx
ƒ E84DFxxxxxxxCxBxxx
ƒ E84DLxxxxxxxCxBxxx
ƒ E84DPxxxxxxxCxBxxx
X81/X82 − RS485 PLC
Pin Signal Description Data
84DPSO05_8
M12 type, 8−pole sockets, A−coded
1 TxD+
RS485A
In accordance with ANSI/TIA/EIA−485−A−98
2 TxD−
RS485B
3 RxD+
RS485A’
4 RxD−
RS485B’
5 n. c.
Not assigned −
6 n. c.
7 GND−EXT
Reference potential
In accordance with IEC 61131−2, type 1
8 +24V
24 V supply
