Commissioning
Preparing the commissioning procedure
8
140
EDS84DPS424 EN 5.0
8.2 Preparing the commissioning procedure
You need the following for commissioning:
ƒ Computer with a Windows® operating system (XP, 7 or 2000)
ƒ Lenze »Engineer« PC software
ƒ Connection to the controller via an interface, e.g.
– diagnostic interface X70 with diagnostic USB adapter
– Fieldbus
ƒ Software manual for the technology application used
ƒ Hardware manual (GHB)
ƒ Manual for the drive−based safety
ƒ Communication manual for the network of the automation platform
ƒ 24 V voltage supply for the control electronics of the controller
– by switching on the mains voltage
– alternatively by a 24−V buffer voltage
Follow the instructions of the software and/or read the documentation.
Selection of the appropriate commissioning tool
There are two ways to commission the 8400 frequency inverter:
ƒ Commissioning using the keypad (or diagnosis terminal)
– For simple drive tasks such as quick commissioning of the ’Speed closed−loop
control’ standard application
ƒ Commissioning using the »Engineer«
– For rather demanding drive tasks such as ’Table positioning’ of the HighLine
version
– Supported by online help and accompanying software documentation (software
manual)
Note!
The following can be used at the diagnostic interface X70:
ƒ Diagnosis terminal X401 (EZAEBK2003)
– The described settings with the keypad X401 can also be carried out with
the diagnosis terminal X401.
ƒ USB diagnostic adapter (E94AZCUS)
