Lenze 8400 protec User Manual

Electrical installation − HighLine/StateLine version
Control terminals
Diagnostics
6

92
EDS84DPS424 EN 5.0
6.6 Control terminals
6.6.1 Diagnostics
The following can be optionally connected to the X70 diagnostic interface:
ƒ USB diagnostic adapter E94AZCUS
In combination with the Lenze PC software »Engineer«, the diagnostic adapter serves
to make comprehensive settings via dialogs, e.g. for initial commissioning.
ƒ EZAEBK2001diagnosis terminal
The diagnosis terminal comprises the keypad including housing and a connecting
cable.
The diagnosis terminal can be used to control or change individual settings. In a quick
commissioning menu, the basic settings of the controller can be parameterised using
the diagnosis terminal.
The X70 plug is located behind the service hatch. Apply a little pressure to open the service
hatch and push the two plastic bars down. Tools are not required.
After using the diagnostic interface, remove the connecting cable at X70 and completely
close the service hatch.
X70 − diagnostic interface
Pin Signal Description Data
Type RJ69, 10−pole, socket
8400HLC009
1 ... 10 internal Terminal for diagnosis terminal or diagnostic adapter

Lenze 8400 protec Specifications

General

Category	DC Drives
Series	8400 protec
Protection Class	IP65
Control Mode	vector control
Communication Interfaces	CANopen, PROFIBUS, PROFINET, EtherCAT, Ethernet/IP
Protection Features	Overcurrent, overvoltage, overtemperature
Relative Humidity	5% to 95% (non-condensing)
Ambient Temperature	-10°C to +45°C
Storage Temperature	-25°C to +70°C
