Lenze 8400 protec - Type Code

Product description
Type code
3

22
EDS84DPS424 EN 5.0
3.3 Type code
StateLine, HighLine

E84D x x x x xxx x x x x x x x
Product range
Inverter Drives 8400 protec
Version
S = StateLine
H = HighLine
Connection system for mains and 24 V supply
M = 2 hybrid plugs, type Q4/2
P = 1 hybrid plug, type Q4/2
H = circular connector Molex (Brad Mini−Change)
Motor holding brake control
(with connection system for motor)
"Fast switch":
B = plug type Modular
Integrated half−wave brake rectifier:
F = plug type Q8/0
"Cold brake":
C = plug type Q8/0
Series
C = 24 V internal
Power, e.g.
152 = 15 x 10
2
W = 1.5 kW
Voltage class
4 = 400/500 V, 3/PE AC
Communication (fieldbus)
C = CANopen
P = PROFIBUS®
R = PROFINET®
G = EtherNet/IP
Configuration of input and output range
see table "Possible combinations",  27
Extension module
S = None
Drive−based safety
N = none
J = safety option 10
K = safety option 20
L = safety option 30
Control element
N = none
C = service switch with protective function
W = service switch with operating unit
Brake resistor
N = none
R = internal
E = external connection option
