Lenze 8400 protec - Power supply units

Accessories (overview)
Power supply units
12

187
EDS84DPS424 EN 5.0
12.7 Power supply units
External power supply units are available for supplying the control electronic with an
external 24−V supply, if required.
Advantages of an external supply: Parameter setting and diagnostics of the controller with
a deenergised mains input.
Mains Secondary
Type V
LN
[V] I
LN
[A] V
DC
[V] I
DC
[A]
EZV1200−000
230
(1/N/PE AC)
0.8
24
(22.5 ... 28.5)
5
EZV2400−000
1.2 10
EZV4800−000
2.3 20
EZV1200−001
400
(3/PE AC)
0.3 5
EZV2400−001
0.6 10
EZV4800−001
1.0 20
