Diagnostics
Display of operating data, diagnostics
Drive diagnostics via the integrated display
10

167
EDS84DPS424 EN 5.0
Error
Group
SettingCAN codeReactionTextAbbr.NumberID
123
99 0x1763 FC1 Limitation of field controller No reaction 0xF000 C00570/4
94 0x175e FCH1 Switching frequency reduction No reaction 0x2000 C00590
95 0x175f FCH2 Maximum speed for Fchop No reaction 0xF000 C00588
57 0x1739 ID1 Error: Motor data identification WarningLocked 0xF000 −
58 0x173a ID3 CINH motor data identification WarningLocked 0xF000 −
59 0x173b ID4 Error in resistor identification Warning 0xF000 −
145 0x1791 LP1 Motor phase failure No reaction 0x3000 C00597
15 0x170f LU DC bus undervoltage Trouble 0x3100 C00600/1
16 0x1710 OC1 Power section short circuit Fault 0x2000 −
17 0x1711 OC2 Power section earth fault Fault 0x2000 −
105 0x1769 OC6 I
2
xt overload − motor Warning 0x2000 C00606
7 0x1707 OC7 Motor overcurrent Fault 0x2000 −
30 0x171e OC10 Maximum current reached Fault 0x2000 −
71 0x1747 OC11 Clamp operation active Warning 0xF000 −
65 0x1741 OC12 I
2
xt overload − brake resistor Fault 0xF000 −
90 0x175a OC13 Exceedance of maximum current for
Fch
Fault 0xF000 −
96 0x1760 OC14 Limitation of direct−axis current
controller
No reaction 0xF000 C00570/1
97 0x1761 OC15 Limitation of cross current controller No reaction 0xF000 C00570/2
98 0x1762 OC16 Limitation of torque controller No reaction 0xF000 C00570/3
31 0x171f OC17 Clamp sets pulse inhibit No reaction 0xF000 C00569/1
32 0x1720 OS1 Maximum speed limit reached No reaction 0x8400 C00579
1 0x1701 OT1 Maximum torque reached No reaction 0x8300 C00608
93 0x175d OT2 Speed controller output limited No reaction 0xF000 C00567
14 0x170e OU DC bus overvoltage Trouble 0x3100 −
205 0x17cd SD3 Open circuit − feedback system Fault 0x7300 C00586
200 0x17c8 SD10 Speed limit − feedback system 12 Fault 0x7300 C00607
201 0x17c9 SD11 Speed limit − feedback system 67 Fault 0x7300 C00607
125
1 0x1901 An01 AIN1_I < 4 mA TroubleQuickStop 0xF000 C00598/1
11 0x190b Io11 DigOut level Warning 0xF000 C00598/3
127
2 0x1b02 CE04 MCI communication error No reaction 0x7000 C01501/1
15 0x1b0f CE0F MCI control word Fault 0xF000 C00594/2
128
5 0x1c05 EDB1 EMS half wave error No reaction − C00596/5
6 0x1c06 EHV1 EMS PowerwaveFail No reaction − C00596/6
7 0x1907 EPV2 EMS DeCaBus error No reaction − C00596/7
