Diagnostics
Display of operating data, diagnostics
Drive diagnostics
10
171
EDS84DPS424 EN 5.0
Display parameters
The parameters listed in the following table serve to get information on current statuses
and actual values of the controller for diagnostic purposes, e.g. with the keypad, via a bus
system or using the »Engineer« (when an online connection has been established to the
controller)
– In the »Engineer« parameter list and in the keypad, these parameters are classified
in the Diagnostics category.
– A detailed description of these parameters can be found in the software manual of
the prevailing device version.
Parameter Display
C00183 Device state
C00168 Error number
C00051 Actual speed value
C00052 Motor voltage
C00054 Motor current
C00057/1 Maximum torque
C00057/2 Torque at maximum current
C00059 Motor − number of pole pairs
C00061 Heatsink temperature
C00062 Temp. inside the controller
C00063 Motor temperature
C00064 Device utilisation (I x t) over the last 180 seconds
C00065 Ext. 24−V voltage
C00066 Thermal motor load (I
2
xt)
C00178 Time the controller was enabled (elapsed−time meter)
C00179 Time the mains was switched on (power−on time meter)
Identification data
The parameters listed in the following table which are classified in the »Engineer«
parameter list and the keypad in the category IdentificationController serve to display
the identification data of the controller.
Parameter Display
C00099 Firmware version
C00200 Firmware product type
C00201 Firmware compilation date
C00203/1 ... 9 HW product types
C00204/1 ... 9 HW serial numbers
C00205/1 ... 6 HW descriptions
C00206/1 ... 6 HW manufacturing data
C00210/1 ... 6 HW version
