Lenze 8400 protec - Page 94

Electrical installation − HighLine/StateLine version
Control terminals
Analog input
6

94
EDS84DPS424 EN 5.0
Example circuit
 
"
GND-A
X50
24O
E84D...
GAAI
AU
AR
GND-A
X50
24O
E84D...
GAAI
AU
AR
=
-
+
"
8400DAI012 8400DAI013
 
"
GND-A
X50
24O
E84D...
GAAI
AU
AR
B
"
GND-A
X50
24O
E84D...
GAAI
AU
AR
B
=
-
+
8400DAI009 8400DAI092
Fig. 6−5 Wiring examples of the analog input
 Potentiometer with internal reference voltage AR
 Potentiometer with external reference voltage
 External master current selection based on a sensor signal 0 − 20 mA.
 External master current selection based on a sensor signal 0 − 20 mA. External
sensor supply.
X50 Connection for analog input
GA GND−A Ground reference potential for the analog inputs and outputs
 EMC shield connection
U Measuring device
B Measuring transducer
