Index table
14
Appendix
14.2
l
14.2-3
EDSPM-TXXX-3.0-04/2004
Index ImportantPossible settingsName
SelectionLenze
I1029
h
Error behavior 0
1
2
3
Pre-Operational
No state changed
Stopped
RESET
Error behaviour
1 Communication
Error
0 The I/O system IP20 switches to the status
set if the communication with the master
fails or ”node guarding”, ”heartbeat”, or
the output moni tori ng have been activated.
2 Manufacturer
Specific Error
0 Only available for the compact system.
If a digital output has a short circuit and
the time set in I2410
h
has been exceeded,
the module switches to the status set.
I1200
h
Server SDO
parameter 1
Display only
Current identifiers for SDO c ommunication
1 SDO1-Rx 1536 (basic identifier) + node address
2 SDO1-Tx 1408 (basic identifier) + node address
I1201
h
Server SDO
parameter 2
Display only
Current identifiers for SDO c ommunication
1 SDO2-Rx 1600 (basic identifier) + node address
2 SDO2-Tx 1472 (basic identifier) + node address
I1400
h
Index is avail a ble in the modular and
compact system
E 9.4-3
1 COB-ID used by
RxPDO 1
768 385 {1} 2047 Defining the individual identifie rs for
process da ta object 1
2 Transmission mode 255 0 {1} 255 Defining the transmission mode
0 Sync-controlled reception The input data are accepted on sync
telegram transmission.
1 ... 240 N-sync-controlled reception The input data are accepted after
transmission of the set number (1 ... 240)
of sync telegrams.
255 Event-controlled reception Every received value is accepted
I1401
h
Index is only a vailable in the modular
system
E 9.4-3
1 COB-ID used by
RxPDO 2
640 385 {1} 2047 Defining the individual identifie rs for
process da ta object 2
2 Transmission type 255 0 {1} 255 Defining the transmission mode
0 Sync-controlled receive The input data are a ccepted on sync
telegram transmission.
1 ... 240 N-sync-controlled reception The input data are accepted after
transmission of the set number (1 ... 240)
of sync telegrams.
255 Event-controlled reception Every received value is accepted
I1402
h
Index is only a vailable in the modular
system
E 9.4-3
1 COB-ID used by
RxPDO 3
512 385 {1} 2047 Defining the individual identifie rs for
process da ta object 3
2 Transmission type 255 0 {1} 255 Defining the transmission mode
0 Sync-controlled receive The input data are a ccepted on sync
telegram transmission.
1 ... 240 N-sync-controlled reception The input data are accepted after
transmission of the set number (1 ... 240)
of sync telegrams.
255 Event-controlled reception Every received value is accepted
