8×digital input / output
5
The modular system
5.9
l
5.9-3
EDSPM-TXXX-3.0-04/2004
Type
8×digital input / output
Voltage supply DC 5 V / 50 mA (via backplane bus)
Connectable cable cross-section ≤ 2.5 mm
2
(≥ AWG 14)
Digital inputs / outputs
Number 8, can be optionally parameterised as inputs or outputs
Electrical isolation from backplane bus Yes, via optocouplers
Digital inputs
Inputs 8
Rated input voltage DC 24 V (DC 18 ... 35 V)
Level LOW:DC0V...5V
HIGH: DC 15 V ... 30 V
Input resistance 3.3 kΩ
Delay time 3ms
Digital outputs
Outputs 8
Rated load voltage DC 24 V (DC 18 ... 35 V)
Max. output current per output 1 A (resistant to short circuits)
Delay time <1ms
Communication
Input data 1byte
Output data 1byte
Dimensions
Width
25.4 mm
Height
76.0 mm
Depth
76.0 mm
Weight 50 g
Order designation EPM-T230
