4×analog input
5
The modular system
5.10
l
5.10-4
EDSPM-TXXX-3.0-04/2004
Type
4×analog input
Voltage supply DC 5 V / 240 mA (via backplane bus)
Connectable cable cross-section ≤ 2.5 mm
2
(≥ AWG 14)
Analog inputs
Number 4
Input area
Voltage -10 ... +10 V
-4 ... +4 V
-400 ... +400 mV
0 ... +50 mV
Current -20 ... +20 mA
+4 ... +20 mA
Information on tolerances
can be found in the chapter
”
P
a
r
a
m
e
t
e
r
s
e
t
t
i
n
g
”
Resistor 60 Ω, 600 Ω,3kΩ,6 kΩ
”Parame
t
er se
t
t
ing”
Resistor, temperature-dependent PT100, PT1000, Ni100,
NI1000
Thermal element J, K, N, R, S, T
Input resistance
Voltage range 2MΩ
Current range 50 Ω
Delay times Conversion time/resolution
Conversion rate [Hz] 3.7 7.5 15 30 60 123 168 202
Processing time per channel [ms] 290 150 84 54 36 28 26 26
Resolution [Bit] 16 16 16 16 15 14 12 10
Electrical isolation from backplane bus Yes, via optocouplers
Communication
Input data 8 bytes (2 bytes per analog input)
Parameter data 10 bytes
Diagnostic data 4bytes
Dimensions
Width 25.4 mm
Height 76.0 mm
Depth 76.0 mm
Weight 100 g
Order number EPM-T310
Technical data
