4×analog output
5
The modular system
5.11
l
5.11-3
EDSPM-TXXX-3.0-04/2004
Type
4×analog output
Voltage supply DC 5 V / 20 mA (via backplane bus)
Extern al voltage supply DC 24 V / 200 mA (DC 19.2 ... 28.8 V)
Connectable cable cross-section ≤ 2.5 mm
2
(≥ AWG 14)
Analog outputs
Number 4 outputs
Output current consumption 200 mA
Analog-to-digital converter 12 bits
Output ranges
Voltage -10 ... +10 V
+1 ... +5 V
0 ... +10 V
Information on tolerances can be
f
o
u
n
d
i
n
t
h
e
c
h
a
p
t
e
r
”
P
a
r
a
m
e
t
e
r
Current -20 ... +20 mA
+4 ... +20 mA
0 ... +20 mA
f
ound in
t
he chap
t
er ”Parame
t
er
setting”
Actuator - input resistance
Voltage range min. 500 Ω
Current range max. 500 Ω
Delay time 10 ms
Electrical isolation from backplane bus Yes, via optocouplers
Communication
Output data 8 bytes (2 bytes per analog output)
Parameter data 6bytes
Diagnostic data 4bytes
Dimensions
Width 25.4 mm
Height 76.0 mm
Depth 76.0 mm
Weight 100 g
Order number EPM-T320
