8400 BaseLine D | Software Manual
Error management
Error messages of the operating system
134 L Firmware 03.00 - DMS EN 5.0 - 07/2009
123 Motor
management /
encoder
8060945 OC2: Power section - earth fault
The device has detected an earth fault of the
motor phases. In order to protect the device
electronics, the inverter control is switched off.
Mostly, faulty motor connections are the reason.
If the sinusoidal filters, motor cable lengths and
cable types (capacity of shielding) are
misdimensioned, discharge currents to PE may
lead to this error message.
1: Error -
pulse inhibit
("Fault")
Check of the motor connections and
the corresponding plug connector at
the device.
Use of sinusoidal filters, cable lengths
and cable types recommended by
Lenze.
123 Motor
management /
encoder
8061033 OC6: I2xt motor overload
Thermal overload of the motor
C00606
Check whether the motor overload
threshold I²xt in code C120
is
dimensioned correctly.
Compliance with load requirements
and, if required, correction of
dimensioning. With control mode
VFCplus:
Check of the Vmin boost, see C00016
For details see
Setting Vmin boost
125 Analog I/O
integrated
8192001 An01: AIN1 I < 4 mA C00598/1 Check wiring of the analog input
terminal for open circuit.
Check minimum current values of the
signal sources.
144 Parameter set 9437185 PS01: No memory module
Memory module is not plugged in.
Either the memory module is not available or not
correctly engaged in the slot.
5: Warning Plug in the memory module or make
sure that it is engaged correctly.
144 Parameter set 9437186 PS02: Invalid parameter set
Parameter set filing invalid due to a previously
incomplete saving of the parameter set (e.g. by
voltage failure or pulling out the memory
module during the saving process).
1: Error -
pulse inhibit
("Fault")
Please make sure during the saving
process that the voltage supply is kept
up and the module remains plugged
into the slot.
144 Parameter set 9437187 PS03: Parameter set of device invalid
Incompatibility of the parameter set is e.g.
caused if the parameter set in the memory
module has a higher version than the basic
device expects.
1: Error -
pulse inhibit
("Fault")
When exchanging the memory
modules, observe the downward
compatibility.
144 Parameter set 9437188 PS04: Invalid parameter set
A memory module incompatible for this device
has been detected.
1: Error -
pulse inhibit
("Fault")
If devices are exchanged, the
parameter sets of the memory module
for the device can be accepted by
means of C002/c012
="1".
144 Parameter set 9437215 PS31: Parameter set of different power class
A parameter set of a memory module has been
detected with a different power class and motor
control SLVC (C006
=4).
1: Error -
pulse inhibit
("Fault")
Execute the motor parameter
identification (C002/c023
="1").
400 Device hardware
defective
26214505 dH69: Adjustment data error
Adjustment data error - power section
1: Error -
pulse inhibit
("Fault")
The device must be returned to Lenze.
980 US01: User error 1 64225281 US01: User error 1
User error 1 of LS_SetError_1
C00581/1
Defined by the user
981 US02: User error 2 64290817 US02: User error 2
User error 1 of LS_SetError_1
C00581/2
Defined by the user
Subject area Error no. Error cause Error
response
Remedy by the user
No. Name
