Lenze L-force 8400 BaseLine D - Page 183

Firmware 03.00 - DMS EN 5.0 - 07/2009 L 183
8400 BaseLine D | Software Manual
Parameter reference
Parameter list | C00054 |
C00054 |
C00056 |
C00057 |
C00058 |
C00059 |
C00061
Parameter | Name:
C00054 | Motor current
Data type: UNSIGNED_16
Index: 24521
d
= 5FC9
h
Display of the current motor current /output current of the inverter
Display range (min. value | unit | max. value)
0.00 A 300.00
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00056 | Torque
Data type: INTEGER_32
Index: 24519
d
= 5FC7
h
Display of the current motor torque
Display range (min. value | unit | max. value)
-99.00 Nm 99.00
Subcodes Info
C00056/1 Torque setpoint
•Only for SLVC operating mode.
C00056/2 Torque actual value
• Estimated actual torque for all operating modes.
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00057 | Maximum torque
Data type: UNSIGNED_32
Index: 24518
d
= 5FC6
h
Display of the maximum torque to be generated by the motor
• The maximum torque to be generated by the motor depends on various factors, e.g. on Imax in motor mode
(C00022
) and the motor type used.
Display range (min. value | unit | max. value)
0.0 Nm 999.9
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00058 | Output frequency
Data type: INTEGER_32
Index: 24517
d
= 5FC5
h
Display of the current output frequency
Display range (min. value | unit | max. value)
-655.0 Hz 655.0
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00059 | Appl.: Reference frequency C11
Data type: UNSIGNED_32
Index: 24516
d
= 5FC4
h
Display of the field frequency which corresponds to the reference speed set in C00011.
Display range (min. value | unit | max. value)
0.0 Hz 999.9
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00061 | Heatsink temperature
Data type: INTEGER_16
Index: 24514
d
= 5FC2
h
Display of the current heatsink temperature
Display range (min. value | unit | max. value)
-50 °C 150
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT Scaling factor: 1
