DSS-1000 User Manual
38
How to Create / Modify Preset Points
1. On the Live View screen, move the mouse over the bottom of the screen to display the
Menu Panel, then click . You must login as an administrator to have PTZ control
access (see 2.3 The Login Screen on page 33 for details).
2. Pan, tilt and zoom the camera to the desired preset point.
3. Click the Preset Point Tab .
4. Click , the icon turns orange. Then click a preset point number to assign.
NOTE: Numbers in red are already configured; when red numbers are selected, the
original preset setting will be overridden with the current preset point.
5. Type a preset point name using the on-screen keyboard (see Using the On-Screen
Keyboard on page 34).
6. Click OK to complete.
How to Delete Preset Points
1. On the Preset Point page tab, click , the icon turns orange.
2. Click the preset point number to remove. The number icon turns gray to indicate that the
preset point is already deleted.
