Chapter 3 Logging Device
http://www.level1.com Page 9
If the screen is shown as follows, it indicates that the connection between the computer and the
device fails.
When connection fails, please check the following items:
1. Hardware connections: The LEDs that correspond to the LAN port on the device panel and
the PC network card LED must be on.
2. Configuring TCP/IP properties of the computer: If the LAN IP address of the device is
192.168.1.1, then the calculated IP address must be any one of the free addresses from
192.168.1.2 - 192.168.1.254.
3.2 Login to the device
When MS Windows, Macintosh, Unix or Linux operating systems are used on the PC, the device
can be configured through browsers (such as Internet Explorer or Firefox).
Open the browser, and type in the IP address of the device's LAN port in the address bar, such as
http://192.168.1.1. After the connection is established, you will see a login interface as shown in
Pinging 192.168.1.1 with 32 bytes of data:
Reply from 192.168.1.1: bytes=32 time<1ms TTL=255
Reply from 192.168.1.1: bytes=32 time<1ms TTL=255
Reply from 192.168.1.1: bytes=32 time<1ms TTL=255
Reply from 192.168.1.1: bytes=32 time<1ms TTL=255
Ping statistics for 192.168.1.1:
Packets: Sent = 4, Received = 4, Lost = 0 (0% loss),
Approximate round trip times in milli-seconds:
Minimum = 0ms, Maximum = 0ms, Average = 0ms
Pinging 192.168.1.1 with 32 bytes of data:
Request timed out.
Request timed out.
Request timed out.
Request timed out.
Ping statistics for 192.168.1.1:
Packets: Sent = 4, Received = 0, Lost = 4 (100% loss),
