Chapter 7 Advanced Configuration
http://www.level1.com Page 57
Figure 7_16 Port VLAN list
VLAN group number: Displays the VLAN group number of the VLAN.
VLAN group name: Displays the VLAN group name of the VLAN.
VLAN members: Displays the members to the VLAN.
4. Port VLAN
Figure 7_17 Port VLAN settings
VLAN group number: Sets the VLAN group number.
VLAN group name: Sets the name of the VLAN group.
VLAN members: Selects the members to the VLAN group.
Tip:
1. The system has a default VLAN (VLAN 1), and it contains all physical ports by default, and
cannot be deleted.
