3-34 Service Manual
5025-2xx, 4xx
202 paper jam
1.
Grasp the front door at the side handholds, and then pull it toward you to open it.
2. Grasp the green lever, and pull the fuser cover toward you.
3. Hold the fuser cover down, and then remove the jammed paper.
The fuser cover closes when released.
4. Close the fuser cover.
5. Close the front door.
6. Press Select ( ) to continue.
