Lexmark C543dn - 200 Paper Jams; 201 Paper Jam; Go Back

Diagnostic aids 3-33
5025-2xx, 4xx
Go Back
Previous
Next
200 paper jams
1.
Remove the standard 250-sheet tray (tray 1).
2. Remove the jam.
Note: Make sure all paper fragments are removed.
3. Insert the tray.
4. Press Select ().
201 paper jam
1.
Grasp the front door at the side handholds, and then pull it toward you to open it.
2. Remove the jammed paper.
Note: Make sure all paper fragments are removed.
3. Close the top door.
4. Press Select ().
