Lexmark MS31x/41x/510/610 & MX310/410/51x/61x Product Study Guide Rev 1.3
Service Menus: MS410 and MS412
Several hidden menus exist to configure advanced settings, troubleshoot problems or obtain additional
printer information. The settings contained in these menus should not be changed unless it is
specifically requested by the Service Manual or Technical Support. Changing the settings may cause
improper operation of the printer.
For a complete list of these menus, consult the Service Manual for the printer.
Diagnostics
Mode
To enter the Diagnostic Menu, do the following:
1. Turn off the printer.
2. Press and hold and .
3. Turn on the printer.
4. Release the buttons when the splash screen
appears.
The Diagnostics Menu contains
advanced settings and operations
used for repair, adjustments or
other diagnostic actions.
Configuration
Menu
To enter Configuration Menu, do the following:
1. Turn off the printer.
2. Press and hold and .
3. Turn on the printer.
4. Release the buttons when the splash screen
appears.
The Configuration Menu contains a
set of menus, settings and
operations which are infrequently
required by a user.
Generally, the options made
available in this menu group are
used to configure a printer for
operation.
Invalid
Engine Code
To enter the Invalid Engine Code state, do the
following:
1. Turn off the printer.
2. Press and hold .
3. Turn on the printer.
4. Release the buttons when the splash screen
appears.
This state allows you to POR the
printer into a mode that disables the
Engine Code and allows the
programming of new code into the
Engine card.
Typically this function is used to
reprogram defective Engine code
but can be useful in other
applications.
Recovery
Mode
To enter Recovery Mode, do the following:
1. Turn off the printer.
2. Press and hold and .
3. Turn on the printer.
4. Release the buttons when the splash screen
appears.
NOTE: Recovery Mode only available
on non-eTask printers.
This mode will allow the printer to
boot from a secondary set of
instructions to allow a code flash to
the printer.
While in this mode, you can ONLY
flash code via USB directly
connected to a PC.
SE Menu
From a browser, add “/se” to the device IP address.
(Example: http://158.183.3.2/se)
Capture diagnostic and debug data.
Safe Mode
To Enable or Disable Safe Mode, do the following:
• Safe Mode state will not disable on
POR without holding down the
