Lexmark MS31x/41x/510/610 & MX310/410/51x/61x Product Study Guide Rev 1.3
Buttons and Functions: MS315dn/MS415dn/MS510dn and MS610dn
Part Description Function
Display
View the printer status and messages.
Set up and operate the printer.
Keypad
Enter numbers, letters, or symbols.
Arrow buttons
Scroll through the menus.
Select button
Select menu options.
Save settings.
Indicator Light
Determine the status of the printer.
Home button
Go to the home screen.
Back button
Return to the previous screen.
Sleep button
Enable Sleep Mode or Hibernate Mode.
The following actions wake the printer from Sleep mode:
• Pressing any hard button
• Opening a tray or the front door
• Sending a print job from the computer
• Performing a power-on reset using the main power switch
• Attaching a device in the USB port
Stop button
Stop all printer activities.
USB port
1
Connect a flash drive to the printer.
Notes:
• Only the front USB port supports flash drives.
• This feature is available only in select printer models.
Only available for the MS610dn printer model.
For Training Purposes Only 35 4/21/2014
