Error code Description Action
140.10 Main drive motor halls not detected See “Main drive motor service check” on page 113.
140.20 Main drive motor took too long to stop See “Main drive motor service check” on page 113.
140.30 Main drive motor unable To lock (before
motor ID)
See “Main drive motor service check” on page 113.
140.40 Main drive motor over speed detected See “Main drive motor service check” on page 113.
140.60 Main drive motor unable to lock (after
motor ID)
See “Main drive motor service check” on page 113.
140.70 Main drive motor out of lock Detected See “Main drive motor service check” on page 113.
140.80 Main drive motor excessive PWM /
Overtemp
See “Main drive motor service check” on page 113.
146.00 Media feeder encoder never detected in
tray 1
See “Media feeder service check” on page 113.
149.00 Redrive motor encoder never detected See “Redrive motor service check” on page 114.
150.00 Duplex motor encoder never detected See “Duplex motor service check” on page 114.
155.00 Toner add motor encoder never detected See “Toner add motor service check” on page 115.
171.03 Main cooling fan error; error took too long
to ramp up
See “Main cooling fan service check” on page 115
171.04 Main cooling fan error; error under speed
or stalled during speed adjustment state
See “Main cooling fan service check” on page 115
171.05 Main cooling fan error; error over speed
during speed adjustment state
See “Main cooling fan service check” on page 115
171.06 Main cooling fan error; error capture data
is invalid and speed control is at maximum
in fan control idle state
See “Main cooling fan service check” on page 115
171.07 Main cooling fan error; error capture data
is invalid and speed control is at maximum
in fan control adjustment state
See “Main cooling fan service check” on page 115
172.03 Cartridge cooling fan took too long to ramp
up
See “Cartridge cooling fan service check” on page 116.
172.04 Cartridge cooling fan under speed or
stalled during speed adjustment state
See “Cartridge cooling fan service check” on page 116.
172.05 Cartridge cooling fan over speed during
speed adjustment state
See “Cartridge cooling fan service check” on page 116.
172.06 Cartridge cooling fan capture data is invalid
and speed control is at maximum in fan
control idle state
See “Cartridge cooling fan service check” on page 116.
172.07 Cartridge cooling fan capture data is invalid
and speed control is at maximum in fan
control adjustment state
See “Cartridge cooling fan service check” on page 116.
173.03 LVPS cooling fan took too long to ramp up See “LVPS cooling fan service check” on page 116.
