Stapler/offset stacker controller PCBA removal
1 Remove the left cover. See “Stapler/offset stacker left cover removal” on page 597.
2 Disconnect all the cables (J11, J5, J6, J4, J26, J24, J22, J23, J17, J3, J2, J1, J18, J15, J1, J12, J14, J8, J20, J9, and J7),
then remove the three screws (A) from the controller PCBA.
