Connector Connects to Pin no. Signal
JFLNDRV Flatbed scanner media length trasmitter
sensor
1V_LED1
2D_LED1
3V_LED2
4D_LED2
5V_LED3
6D_LED3
JICC Connects to ADF controller board N/A N/A
JSTEP1 Flatbed scanner drive motor 1 OUT1A
2OUT1B
3OUT2A
4OUT2B
7463
Component locations
