Assembly 3: Paper path
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X7602 1 1 Upper redrive See “Upper redrive removal” on page 363.
2 40X7588 1 1 Fuser access door (MX81x) See “Fuser access door removal” on
page 349.
2 40X8399 1 1 Fuser access door (MX71x) See “Fuser access door removal” on
page 349.
3 40X7587 1 1 Inner guide deflector See “Inner guide deflector removal” on
page 318.
4 40X7585 1 1 Recoil spring N/A
5 40X7584 1 1 Duplex exit diverter See “Duplex exit diverter removal” on
page 314.
6 40X7583 1 1 Media turn guide See “Media turn guide removal” on
page 325.
7 40X7586 1 1 Media vertical guide See “Media vertical guide removal” on
page 326.
7463
Parts catalog
682
