Diagnostic information 2-81

4060-xxx

Lines spaced 49.74 mm

(1.958 inch) apart

Replace the FRUs in the following order:

• Redrive assembly

• Fuser assembly

There is a danger from hazardous voltage in the area of

the printer where you are working. Unplug the printer

before you begin, or use caution if the printer must

receive power in order to perform the task.

Lines spaced 51.02 mm

(2.009 inch) apart

Replace the transfer roll.

Lines spaced 52.23 mm

(2.056 inch) apart

Replace the redrive assembly.

Lines spaced 76.53 mm

(3.013 inch) apart

Replace the FRUs in the following order:

• Alignment assembly

• Main drive gearbox assembly

Lines spaced 95.66 mm

(3.766 inch) apart

Replace the FRUs in the following order:

• Toner cartridge

• Main drive gearbox assembly

Lines spaced 99.49 mm

(3.917 inch) apart

Replace the redrive assembly.

Lines spaced 114.79 mm

(4.519 inch) apart

Replace the alignment assembly.

FRU Action
