Lexmark T632 - Assembly 4: Printhead 1 (000;010)

7-10 Service Manual
4060-xxx
Assembly 4: Printhead 1 (000/010)
Asm-
index
Part
number
Units Description
4—1 56P1386 1 Cable, laser
2 99A0263 3 Parts packet, screw (printhead mounting)
3 56P1396 1 Printhead assembly (includes all cables), 000/010
4 56P1387 1 Cable, HSYNC
5 56P1388 1 Cable, mirror motor, 000/010
000/010
1
2
3
4
2
5
