Lexmark T632 - Page 175

Repair information 4-21
4060-xxx
6. Remove the paper alignment assembly. See “Paper alignment assembly removal” on
page 4-52.
7. Remove the left side frame mounting screws (A).
8. Place the printer on its back and remove the left side frame mounting screws (B).
9. Remove the left side frame.
A(102)
B(104)
