Lexmark T632 - Page 178

4-24 Service Manual
4060-xxx
Installation
1. When you reinstall the fuser, be sure to route the fuser lamp cable through the channel (F) on
the right side frame above the LVPS, under the clip (G), and through the notch in the frame (H)
2. Route the fuser lamp cable through the opening in the fuser as shown (J).
F
G
H
J
