Repair information 4-29
4060-xxx
4. Remove the left lamp contact assembly.
5. Remove the fuser lamp.
Warning: The lamp is under spring tension and care must be used when removing the lamp
from the fuser. Grip the lamp by the ceramic end piece and remove it from the fuser
assembly. Be careful not to touch the glass as skin oils and acids can reduce the life
of the lamp.
Use the following table to identify and install the correct lamp.
Description P/N
Fuser Lamp 115 V 56P1362
Fuser Lamp 220 V 56P1363
