Lexmark T632 - Page 190

4-36 Service Manual
4060-xxx
7. Locate the integrated tray autocompensator assembly (A) on the bottom of the printer and
disconnect the autocompensator arm bias spring (B).
Note: When you remove the spring, note the larger loop attaches to the side frame.
8. Remove the C-clip (C) that rests against the right side frame from the autocompensator pivot
shaft.
A BC
