Parts catalog 7-3
4060-xxx
Assembly 1: Covers
Asm-
Index
Part
number
Units Description
1—1 56P1300 1 Cover, fuser wick assembly
2 99A2074 1 Cover assembly, redrive cap
3 56P1301 1 Cover assembly, laser assembly, 250-sheet output, 000/010
3 56P1302 1 Cover assembly, laser assembly, 500-sheet output, 200/210/400/410
4 56P2797 1 Support, paper assembly
5 56P1305 1 Hinge, upper front cover
6 56P1306 1 Cover, right side, 250-sheet output, 000/010
6 56P1307 1 Cover, right side 500-sheet output, 200/210/400/410
7 99A0007 1 Label, TLI/ID/serial number—blank
8 56P1303 1 Upper front cover with Lexmark logo
9 56P1308 1 Latch, upper cover
10 56P1309 1 Cover assembly, lower front
11 99A0004 1 Spring, latch
12 56P1356 1 Cover, clear bezel, 000/010
12 56P1358 1 Cover, clear bezel, 200/210
12 56P1862 1 Cover, clear bezel, 400/410
13 56P1753 1 Kit, operator panel overlay—English, Brazilian Portuguese, French, and Spanish
13 56P1754 1 Kit, operator panel overlay—Dutch, French, German, and Italian
13 56P1755 1 Kit, operator panel overlay—Czech and Hungarian
13 56P1756 1 Kit, operator panel overlay—Danish, Finnish, Norwegian, and Swedish
13 56P1757 1 Kit, operator panel overlay—Polish, Russian, and Turkish
13 56P1758 1 Kit, operator panel overlay—WW English and Spanish
13 56P1759 1 Kit, operator panel overlay—WW English, Simplified Chinese, Traditional Chinese, and
Japanese
14 56P1310 1 Operator panel assembly 110V
14 56P1311 1 Operator panel assembly 220V
15 56P1394 1 Cable assembly, operator panel
16 56P2122 1 Cover, left door, 250 1-slot, 000/010
17 99A1524 1 Cartridge load spring
18 56P1395 1 Switch, cover closed w/cable assembly
19 56P2126 1 Cover, left door, 500 2-slot, 200/210/400/410
NS 99A0577 1 Parts packet, cable ties (10 each)
NS 99A1594 1 Retainer, cable
NS 99A0263 5 Parts packet, screw (left side cover mounting)
NS 99A0263 3 Parts packet, screw (right side cover mounting)
NS 99A0263 6 Parts packet, screw (laser cover)
NS 99A0263 5 Parts packet, screw (upper front cover mounting)
