Parts catalog 7-7
4060-xxx
Assembly 3: Frame 2
Asm-
index
Part
number
Units Description
3—1 99A1857 1 Upper redrive deflector
2 99A0104 1 Upper diverter spring
3 99A2151 1 Redrive assembly, 250 in/250 out, 000/010
3 56P1328 1 Redrive assembly, 500 in/500 out, 200/210/400/410
4 56P1318 1 Duct, main cap
5 99A0263 3 Parts packet, screw
6 99A2021 1 Support, right stacker plate, 000/010
6 56P1319 1 Support, right stacker plate, 200/210/400/410
7 99A2020 1 Transfer plate assembly
8 99A2077 4 Pad, machine mounting
9 56P1399 1 Smart cartridge contact assembly w/cable
10 56P1408 1 Cartridge fan
11 56P1361 1 Toner sensor assembly
12 99A0585 1 Parts packet, contact kit
• Contact, doctor blade/TAR/developer roll (3)
• Contact, PC drum (1)
• Contact, charge roll (1)
• Block, contact mounting (4)
• Screw, contact mounting (5)
13 99A0028 1 Spring, tray bias
14 99A2019 2 Spring, cartridge hold down
15 99A0026 1 Tray bias arm assembly
16 99A0039 2 Roller, developer support
17 99A1525 1 Deflector, upper PF
18 56P1334 1 Deflector, inner, 000/010
18 56P1336 1 Deflector, inner, 200/210/400/410
19 99A0053 1 Sensor, input
20 99A1546 1 Shield, gear #60/MPF
21 99A0549 1 Shield, ESD assembly with label
22 99A2445 1 Guard, gear
23 99A2078 1 Pan, motor drip
24 56P1350 1 Board, input tray (ITC)
25 99A2076 1 Pan, drip ITC
26 99A0063 1 Paper switch activate
27 99A0567 1 Link, gear release
28 99A0556 1 Spring, counterbalance
29 56P1314 1 Shroud, fan, 000/010
29 56P1315 1 Shroud, fan, 200/210/400/410
30 56P1391 1 Sensor, standard bin level with cable
31 99A0062 1 Bracket, level sensor
32 56P1360 1 Fan, main w/cable
33 99A2018 1 Support, left lower stacker
