Parts catalog 7-15
4060-xxx
Assembly 8: Paper feed—multipurpose feeder
Asm-
index
Part
number
Units Description
8—1 99A0075 1 Screw, socket set M4X5 mm
2 99A0071 1 Arm assembly, MPF
3 99A0076 1 Pick roll assembly
4 99A0084 1 Flag, MPT paper out
5 56P1352 1 MPF pad/separator arm assembly, includes:
• Pad, restraint
• Pad, separator
• Housing, separator pad
• Spring, sep pad
•Arm, separator
• Spring, sep
6 99A1531 1 MPF lower deflector
7 99A0263 2 Parts packet, screw (lower deflector mounting 8 mm)
7 99A0263 2 Parts packet, screw (lower deflector mounting 12 mm)
8 99A2071 1 Sensor, MPF paper out
9 99A0081 1 Spring assembly, separator
10 99A0263 1 Parts packet, screw (frame mounting)
11 99A0073 2 Screw, damper
12 99A0074 2 Bushing, pick roll shaft
13 56P2407 1 MPF frame assembly with solenoid
NS 99A0267 2 Parts packet, clip (pick roll shaft)
