Parts catalog 7-23
4060-xxx
Assembly 12: Drives—Main drive and developer drive
Asm-
index
Part
number
Units Description
12—1 56P1330 1 Gearbox, w/motor, 000/010
1 56P1332 1 Gearbox, w/motor, 200/210
1 56P1858 1 Gearbox, w/motor, 400/410
2 99A0134 1 Shaft, power takeoff 250, 000/010
2 99A1569 1 Shaft, power takeoff 500, 200/210/400/410
3 99A0275 1 Spring, power takeoff shaft
4 56P2162 1 Gear, bevel with grease packet and washer
5 99A1544 1 Developer drive assembly
6 99A2081 1 Parts packet, developer drive shaft, coupler gear #55
7 99A0263 3 Parts packet, screw (developer drive ground)
NS 99A0263 4 Parts packet, screw (gearbox mounting)
NS 99A0263 3 Parts packet, screw (motor mounting)
