Parts catalog 7-25
4060-xxx
Assembly 13: Hot roll fuser
Asm-
index
Part
number
Units Description
13—1 56P2542 1 Fuser assembly w/115V lamp, 000/010/200/210
1 56P2543 1 Fuser assembly w/100V lamp, 000/010/200/210
1 56P2544 1 Fuser assembly w/220V lamp, 000/010/200/210
1 56P2545 1 Fuser assembly w/115V lamp, 400/410
1 56P2546 1 Fuser assembly w/220V lamp, 400/410
1 56P2547 1 Fuser assembly w/100V lamp, 400/410
2 99A1658 1 Cover, fuser wiper cavity
3 56P1415 1 Wiper assembly, wet
4 56P1348 1 Kit, fuser cover assembly with thermistor, thermal fuse, and L & R fuser lamp contact
assemblies, w/ fuser cover control card
5 99A0263 4 Parts packet, screws:
• Contact assembly (4)
• Solenoid mounting (1)
• Board cover mounting (1)
• Fuser cover assembly (4)
• Hanger (7)
6 56P1362 1 Lamp, 115V, 000/010/200/210
6 56P1363 1 Lamp, 220V, 000/010/200/210
7 2 Screw, PP 99A0263
8 56P1402 1 Sensor, narrow media
9 56P1403 1 Sensor, exit
