Parts catalog 7-27
4060-xxx
Assembly 14: Transfer/charging
Asm-
index
Part
number
Units Description
14—1 99A0512 1 Parts kit, charge roll link asm, left side
2 99A1017 1 Roll assembly, charge
3 99A1555 1 Bushing, charge roll
4 99A0513 1 Parts kit, charge roll link asm, right side
5 56P1357 1 Transfer roll assembly
6 99A0349 1 Arm, transfer roll assembly right
7 99A0184 1 Spring, transfer roll right
8 99A0185 1 Shaft, transfer pivot
9 99A0181 1 Spring, transfer roll left
10 99A1578 1 Arm, transfer roll left
NS 99A0263 1 Parts packet, screw (charge roll)
NS 99A0267 1 Parts packet, retainer (pivot shaft)
