Lexmark T632 - Page 281

Parts catalog 7-45
4060-xxx
Assembly 22: 500-sheet paper tray
Asm-
index
Part
number
Units Description
22—1 99A0350 1 Sensor, paper low
2 99A0263 3 Parts packet, screw (auto comp mounting)
3 99A0405 1 Pick arm assembly
4 99A0070 2 Pick roll assembly
5 56P2540 1 Spring, bellcrank 500-sheet option tray
6 56P1337 1 Parts packet, bellcrank and spring
7 99A1636 1 Base, 500-sheet tray
8 99A0058 4 Pad, base 500-sheet
9 99A0419 1 Spring, tray bias
10 99A0026 1 Tray bias arm assembly
11 99A0288 1 Sensor, option pass thru
12 99A0895 1 Restraint, side 500-sheet tray
13 99A0292 4 Wear strips
14 99A1829 1 Label, tray option number
15 99A1583 1 Plate, 500-sheet tray wear
16 99A0126 3 Finger, autosize
17 99A0124 1 Plate, snap-in
18 99A1952 1 Label, paper size
19 99A1582 1 Slider, autosize 500-sheet
20 99A0120 2 Restraint pad
21 99A1576 1 Tray assembly, 500-sheet
22 99A1537 1 Knob, paper size
23 99A1602 1 Restraint, back 500-sheet tray
24 99A1601 1 Latch, back restraint
25 99A1666 1 Label, options
26 56P0557 1 Board, option tray
27 99A0447 1 Shaft, 500-sheet drive
28 99A0282 1 Cable, 250 autoconnect
29 99A1750 1 Wear plate, pass thru
30 99A0276 1 500 Drive roll assembly
31 99A0263 2 Parts packet, screw (wear plate mounting)
32 99A0450 1 Retainer, roller
33 99A0451 1 Roller, skewed backup
34 99A0438 2 Bushing, drive roll
35 99A0275 1 Spring, power takeoff
36 99A0263 3 Parts packet, screw (board mounting)
37 99A0267 1 Parts packet, retainer (aligner assembly)
38 99A0280 1 Bearing, drive shaft low
39 99A0446 1 Aligner assembly, paper
40 99A0274 1 Gear, feed roll
41 99A0063 1 Spring, switch activate
