Parts catalog 7-47
4060-xxx
Assembly 22 (cont.): 500-sheet paper tray
Asm-
index
Part
number
Units Description
22—42 99A0286 1 Spring, backup roller
43 99A1664 1 Bellcrank, roller release
44 99A0273 1 Gear, bevel
45 99A0279 1 Bearing, drive shaft
46 99A0281 1 Cable, 250-sheet autoconnect
47 99A1702 1 Stud assembly, 500 frame
48 99A1645 1 Arm, paper out 500
NS 99A0452 4 Washer, frame mounting
NS 99A1665 1 Deflector, base 500
NS 99A1667 2 Bracket, 500-sheet tray retention
