Lexmark T632 - Page 287

Parts catalog 7-51
4060-xxx
Assembly 24: Envelope feeder
Asm-
index
Part
number
Units Description
24—1 99A0389 1 Paper weight assembly
2 99A1694 1 Guide, edge
3 99A1696 1 Cover, top
4 99A0485 1 Sensor, envelope pass thru
5 99A0393 1 Clutch, restraint/gear
6 99A1697 1 Cover, right side
7 99A0390 1 Support, slide out
8 99A0488 7 Roller, support
9 99A0382 1 Motor, stepper DC
10 99A1666 1 Label, options
11 99A0388 1 Switch, envelope out
12 99A1700 1 Board assembly, electronic control
13 99A0271 1 Parts packet, gear kit
14 99A1698 1 Cover, left side
NS 99A0404 1 Parts packet, retainer (4 mm PP)
NS 99A0404 3 Parts packet, retainer (clip 5 mm shaft)
NS 99A0404 2 Parts packet, retainer (6 mm)
NS 99A0404 3 Parts packet, retainer (7 mm shaft)
NS 99A0384 1 Shaft, drive pressure roller
NS 99A0385 1 Cable, auto connect front
NS 99A0494 1 Spring, cam clutch
NS 99A0427 1 Label, envelope orientation icon
NS 99A0469 1 Deflector guide
NS 99A1699 1 Guard, pass thru sensor
NS 99A0413 6 Screw, top/motor/board
NS 99A0484 1 Belt, gear drive
NS 99A0491 1 Bracket, stack limiter
NS 99A0400 1 Spring, restraint roll shaft
NS 99A0489 1 Spring, latch return
NS 99A0487 1 Flag, envelope out sensor
