Parts catalog 7-53
4060-xxx
Assembly 25: Output expander
Asm-
Index
Part
Number
Units Description
25—1 99A1857 1 Deflector, upper redrive, also order 99A0104
2 99A0104 1 Spring, upper diverter
3 99A0369 1 Shaft assembly, exit, also order PP 99A0572
4 99A0052 1 Shaft assembly, lower exit, also order PP 99A0572
5 11 Screw, PP 99A0263
6 99A0915 1 Board, output expander DC motor
7 99A0571 1 Cover, front control board with ESD brush
8 99A1817 1 Tray, output expander
9 99A1666 1 Label, options
10 99A1689 1 Spring clutch assembly
11 99A1688 1 Diverter arm
12 99A0482 1 Spring, output tray
13 99A1784 2 Bracket, attach
14 99A0914 1 Output expander assembly, mechanical linkage
15 99A0372 1 Cover, left side
16 99A0415 2 Spring, swing arm
17 99A0481 1 Latch, output tray
18 2 Shaft bearing PP 99A0572
19 99A0409 1 Level sensor bracket
20 99A1580 1 Flag, output paper level
21 99A0414 1 Sensor, dual bin full
